120,000 Tons/year Premix and 60,000 Tons/year Livestock Ruminant and Poultry Concentrated Feed Production Line Project

  • Clicks:

With the continuous increase of the global population, the demand for meat, eggs, milk, fish, skin, hair, honey and other livestock and aquaculture products is also increasing. The huge population's demand for aquaculture products will be the main motivation for the development of the feed industry. The increasingly strong and diversified market demand for aquaculture products has brought broad development prospects to the feed industry. The development of the feed industry can promote the development of animal husbandry, effectively save food, drive the farmers to work hard to become rich, and stimulate the development of the national economy.

120,000 Tons/year Premix and 60,000 Tons/year Livestock Ruminant and Poultry Concentrated Feed Production Line Project
120,000 Tons/year Premix and 60,000 Tons/year Livestock Ruminant and Poultry Concentrated Feed Production Line Project

After the project is completed, it can form an annual production scale of 120,000 tons of premix and 60,000 tons of full price concentrated feed. During the operation of the project, there are two shifts per day, with 8 hours of working time per shift and 300 working days in a year. Converted into hourly output is 25 tons/hour premix and 12 tons/hour full price concentrated feed production line project. The total land area of ​​the project is 47,713.33 square meters (71.57 mu), and the total construction area is 32,219.04 square meters.

1. Construction Content and Scale

(1) Project name: Livestock ruminant poultry feed pellet production line project

(2) Annual output: 120,000 tons/year premix and 60,000 tons full price concentrated feed production line project

(3) Hourly output: 25 tons/hour premix and 12 tons/hour full price concentrated feed production line

(4) Feed type: fish feed, cattle feed, dairy cow feed, poultry feed, sheep feed, pig feed, horse feed and pet feed

(5) Construction status: The project site is currently a vacant land, and construction has not yet started. The construction content of this environmental assessment is that the project covers an area of ​​about 71 mu, constructs 12,000 square meters of workshops, 11,700 square meters of warehouses, and 1,200 square meters of office buildings, purchases multiple sets of micro-ingredients, crushing, mixing, and packaging equipment, and builds 3 premixed feed production lines, 1 full-price concentrated feed production line, which is consistent with the content of the record. The construction unit considered that the company will expand in the later period. For this reason, the EIA is defined as the first phase of the project. The total investment of the project is 180 million RMB. It is expected to start construction in March 2019 and end in November 2020.

(6) Construction content: The total construction area of ​​this project is 32219.04m2. With an annual output of 120,000 tons of premix and 60,000 tons of full price concentrated feed.

Livestock Ruminant and Poultry Concentrated Feed Production Line Project
Livestock Ruminant and Poultry Concentrated Feed Production Line Project


Table 1-1 List of main construction contents of this project

project Construction name Area (㎡) Building area (㎡) Capacity area (㎡) Above ground (under)
(layer)
Height
(m)
Pollution
case
structural work Plant Livestock/concentrated feed/premix workshop On the ground 1,119.73 12740.00 12740.00 11 49.80 Exhaust gas, solid waste
underground 1315.96 -2
Auxiliary engineering warehouse Finished product warehouse and ancillary buildings 5863.85 5863.85 10,790.45 1 9.10 Exhaust gas, solid waste
Office building and ancillary projects

Car unloading shed & silo workstation On the ground 894.00 495.54 722.34 7 19.70 Exhaust gas, solid waste, noise
Structures on the ground 69.00 7
Underground structure 360.90 -1
Raw material library On the ground 7710.00 7767.00 15477.00 1 9.33 Exhaust gas, solid waste
Underground structure 363.80 -1
Comprehensive Building 874.29 1,779.76 1,779.76 2 9.70 Solid waste
Doorman 1 180.00 190.70 190.70 1 4.00 Solid waste
Auxiliary room 468.00 468.00 468.00 1 4.40 noise
Power & solid waste On the ground 729.77 410.00 410.00 1 6.80 Solid waste, noise
Structures on the ground 319.77 0.00 1
Oil tank 56.50 0.00 0.00 - - /
Bicycle shed 100.80 50.40 100.80 - 2.60 /
Wastewater treatment Underground structure - 16.20 - -1 - Waste water
Class A library 8.16 8.16 8.16 1 3.80 /
Doorman 2 18.00 18.00 18.00 1 4.00 Solid waste
total 18077.10 32219.04 42,687.21 / / /
Environmental Engineering Pretreatment, sedimentation tank, grease trap, septic tank After pretreatment, laboratory wastewater enters the septic tank through the plant sewage pipe network for treatment. The clean wastewater from the workshop is settled in the sedimentation tank and then enters the septic tank through the plant sewage pipe network for treatment. The canteen wastewater passes through the plant sewage pipe network after being treated by the grease trap After entering the septic tank for treatment, domestic sewage enters the septic tank for treatment, and the wastewater from the main outlet of the septic tank enters the municipal pipe network, is discharged into the sewage treatment plant of the Economic Development Zone, and is discharged into Yuanshui. Waste water
Oil fume purifier After the oil fume exhaust gas is treated by the oil fume purifier, it is discharged through the roof of the special flue. Exhaust
Pulse dust collector After the boiler exhaust gas is treated by the pulse dust collector, it is discharged through a 15-height exhaust tube Solid waste, exhaust gas
canteen The oil fume exhaust gas is collected by the air collecting hood, and then treated by the electrostatic oil fume purifier, and then guided to the roof of the building for discharge Exhaust
silencer Measures such as basic vibration reduction, muffler, and sound insulation of factory buildings are adopted for noise of machinery and equipment noise
Solid waste storage room Construct a 108m 2 solid waste storage room next to the generator room on the north side of the plant Solid waste
Public works Water supply Supplied by the municipal water pipe network
powered by Powered by the municipal grid
Gas supply Pipeline natural gas

2. Main Equipment

The main equipment is shown in Table 1-2.

Table 1-2 List of main equipment

Serial number Device name model Quantity (set/set) Placement
1 Quality Keeper STZL600 1 Crushing system workshop
2 Superfine grinder SWFL130G 1
3 Settlement chamber   5
4 Finished product warehouse   20
5 Hammer Mill SWFP66*80D 3
6 Crusher MUSL24×110 2
7 To be crushed   7 Raw material distribution system workshop
8 To be mixed warehouse   55
9 Puffing warehouse   2
10 To be granulated bin   4
11 Single shaft paddle mixer SJHS0.5 1
12 Distributor TFPX4-300 3
13 Distributor TFPX12-300 1
14 Distributor TFPX8-300 4
15 Distributor TFPX6-200 2
16 Powder inspection sieve SCQZ51*46*90 2
17 Scraper conveyor TGSP32 5
18 Scraper conveyor TGSP25 8
19 Scraper conveyor TGSP20 11
20 Electronic packing scale PDC50 6
twenty one Distributor TFPX8-250 1
twenty two Distributor TFPX6-200 6
twenty three Distributor TFPX10-200 2
twenty four Distributor TFPX6-250 4
25 Distributor TFPX10-250 1
26 Dryer   1 Conveying and distribution system workshop
27 Rotary vibrating screen SFJH130×2C 1
28 Mixer discharge hopper   1
29 Feed Pellet machine SZLH420 1
30 Cooler SLNF22×22A 2
31 Leveler   1
32 Screw conveyor TLSGf32 3
33 Screw conveyor TLSU25 1
34 Single shaft paddle mixer SJHS2A 3
35 Single shaft paddle mixer SJHS4 1
36 Single shaft paddle mixer SJHS1 1
37 Powder inspection sieve SCQZ90*80*110 10
38 Scraper conveyor TGSS20 7
39 Biaxial paddle mixer SJHS4D 1
40 Biaxial paddle mixer SLHSJ2 1
41 Hoist T600 3
42 Hoist T400 12
43 Hoist T500 1
44 Hoist T360 1
45 Belt conveyor sewing machine   8
46 To be mixed warehouse   177 Mixing system workshop
47 Mixer SJHS0.5 3
48 Mixer SJHS0.2 1
49 Extruder   1
50 Cleaning screen TCQY80 2 other devices
51 Cleaning screen TQLZ150×200 1
52 Shakron SKLX55-1600 2
53 Shakron SKLX55-1400 2
54 Maturator   1
55 Modulator MUTZ420 4
56 Silo   6
57 Feeder   10
58 Field control cabinet   1
59 Permanent magnet cylinder   8
60 Permanent magnet cylinder TCXT25 5
61 Cylindrical cleaning screen TCQYS100 1
62 Impurity warehouse   1
63 Automatic palletizing system   1
64 Automatic feeder TWLY80ZD 2

3. Main Raw and Auxiliary Materials

The main raw and auxiliary materials consumption are shown in Table 1-3.

Table 1-3 Raw material and energy consumption table

Serial number Name of raw and auxiliary materials Annual consumption (t/a) Packing Remarks
1 Soybean meal-43% 29314 Packed in bags, 50kg/bag Solid, granular
2 Fine stone powder 26818 Packed in bags, 50kg/bag Solid, powder
3 Powdered calcium hydrogen phosphate 14478 Packed in bags, 50kg/bag Solid, powder
4 Attapulgite 12764 Packed in bags, 50kg/bag Solid, granular
5 salt 9390 Packed in bags, 50kg/bag Solid, powder
6 Imported fish meal 7606 Packed in bags, 50kg/bag Solid, powder
7 Bean curd 6760 Packed in bags, 40kg/bag Solid, powder
8 Puffed soybeans 6110 Packed in bags, 40kg/bag Solid, powder
9 corn 5643 In bulk Solid, granular
10 Monocalcium phosphate 4941 Packed in bags, 50kg/bag Solid, powder
11 Corn gluten feed 4561 Packed in bags, 40kg/bag Solid, powder
12 Expanded corn 4331 Packed in bags, 40kg/bag Solid, powder
13 Concentrated pig feed 3583 Packed in bags, 40kg/bag Solid, powder
14 Low protein whey powder 3286 Packed in bags, 25kg/bag Solid, powder
15 Defatted rice bran 3194 Packed in bags, 40kg/bag Solid, powder
16 flour 2156 Packed in bags, 40kg/bag Solid, powder
17 Pig trace element premix 2138 Packed in bags, 40kg/bag Solid, powder
18 Defatted rice bran-carrier 2039 Packed in bags, 40kg/bag Solid, powder
19 sugar 2004 Packed in bags, 50kg/bag Solid, granular
20 Choline chloride 60% 1828 Packed in bags, 25kg/bag Solid, powder

4. Product Plan

The product scheme of this project is detailed in the following table 1-4.

Table 1-4 List of project product plans

Serial number product name Annual output (t/a)
1 Premixed feed 120000
2 Concentrated feed 37,000
3 Pig compound feed 18,000
4 Poultry compound feed 5,000

5. Labor Quota and Work System

The labor quota for this project is 80 people. There are two shifts per day, the working time of each shift is 8 hours, and the number of working days in a year is 300 days.

If you are interested in our products or project solutions, please contact us. We will give you the best product quality and the best price. Email: sales@cnrichi.cn
