200,000 Tons/year Livestock Poultry Feed Line & 100,000 Tons/year Pig Feed Pellet Production Line Project
- Date: 2020-11-23 08:39:49
- From: www.pellet-richi.com
- Clicks:
According to market needs, the project built 3 new livestock and poultry pellet production line, forming a 200,000-ton poultry pellet production line and a 100,000-ton pig feed pellet production line. Among them, the feed pellet machine, pulverizer, mixer, and cooler are the four essential hosts in this production line. An annual output of 200,000 tons of livestock and poultry feed lines and a 100,000 tons/year pig feed pellet production line, converted by hourly output, are 40 tons/hour poultry feed line and 20 tons/hour pig feed line projects.
What equipment is needed to build a large-scale 200,000-ton/year livestock and poultry feed line and 100,000-ton/year pig feed pellet production line? Below we show in detail the equipment name, equipment model and quantity required.
200,000 Tons/year Livestock Poultry Feed Line & 100,000 Tons/year Pig Feed Pellet Production Line Project
Table 1 List of equipment list for large-scale livestock and poultry feed pellet production line
| Work section | name | Scale model | Quantity (set/set) |
| Bulk raw material receiving | Wind shut | GFDZY-10 | 3 |
| Bucket elevator | AHGL630*440 | 2 | |
| Scraper conveyor | LLCA200 | 5 | |
| Chakron | φ1250mm | 1 | |
| Cylindrical cleaning screen | SCY125 | 1 | |
| Fan | 4-72-5A | twenty one | |
| Pulse dust collector | AHMB48 | 16 | |
| Pneumatic tee | AHBQ300*35° | 2 | |
| Feeder | 20 | ||
| Unloading pit, grid screen | 1 | ||
| air hammer | AH40 | 1 | |
| Unloading level device | 10 | ||
| Rotary distributor | TFPX-8*300 | 1 | |
| Silo cone | 45m³×10 | 10 | |
| Pneumatic gate under the scraper | 14 | ||
| Permanent magnet cylinder | TCXT40 | 1 | |
| Pneumatic gate | AHMQ40 * 40 | 15 | |
| Buffer bucket | 10×1m³ | 10 | |
| Temperature measuring probe and system | 10 | ||
| Wind net | φ350mm | 9 | |
| Widened vibration cleaning screen | ZDS200 | 1 | |
| Lifting scraper | MCTG50 | 5 | |
| Flow scale | 150 tons/hour | 2 | |
| Vibrating Unloader | φ2500 | 5 | |
| Workshop raw material receiving | Bucket elevator | TDTG50/28 | 3 |
| Wind shut | GFDZY-10 | 3 | |
| Cylindrical cleaning screen | SCY100 | 2 | |
| Cone powder sieve | SQLZ90 | 1 | |
| Fan | 4-72-4.5A | 9 | |
| Pulse dust collector | AHMB48 | 9 | |
| Granular material feeding pit, grid screen | 3 | ||
| Pneumatic tee | 1 | ||
| Permanent magnet cylinder | TCXT30 | 3 | |
| Transfer distributor | TFPX-8*250 | 3 | |
| Flow scale | 100 tons/hour | 3 | |
| Wind net | φ300mm | 3 | |
| Lifting scraper | MCTG30 | 3 | |
| Smash | Fan | 6-30-7C | 4 |
| Bucket elevator | TDTG50/28 | 4 | |
| Fan | MKV-012R | 4 | |
| Feeder | AHLY980 | 4 | |
| Pulse dust collector | AHMB64L | 8 | |
| To be crushed | Total 293m³ | 8 | |
| grinder | AHZC06120 | 4 | |
| Feeder | 8 | ||
| Unloading level device | 8 | ||
| Settlement chamber | 3m³ | 4 | |
| Screw conveyor | AHSG315 | 4 | |
| Rotary distributor | TFPX-12*250 | 4 | |
| Pneumatic gate | AHMQ40 * 40 | 8 | |
| Buffer bucket | 0.6m³ | 4 | |
| Wind net | φ500mm | 4 | |
| silencer | φ500mm | 4 | |
| mixing | Ingredient warehouse group | 36 | |
| Wind shut | 3 | ||
| Bucket elevator | TDTG50/28 | 2 | |
| Scraper conveyor | LLCA100 | 7 | |
| Small material compound scale | 200KG/batch | 3 | |
| Cone powder sieve | SQLZ90 | 1 | |
| Fan | 9-19-5.6A | 7 | |
| Pulse dust collector | AHMB6L | 7 | |
| Pneumatic tee | AHBQ200 * 70 ° | 8 | |
| Feeder | 36 | ||
| Small feed inlet | AHFZ75B | 3 | |
| air hammer | 50 | ||
| Unloading level device | 36 | ||
| Mixer | AHHJ4 | 3 | |
| Air delivery system | φ100mm | 1 | |
| Batching scale | 1500KG/batch | 4 | |
| Rotary distributor | TFPX-6*250 | 3 | |
| Batching scale | 200KG/batch | 2 | |
| Screw conveyor | AHSG200 | 36 | |
| Single wing butterfly valve | DN600 | twenty two | |
| Permanent magnet cylinder | TCXT30 | 3 | |
| Pneumatic gate under the scraper | 2 | ||
| Pull sensor | PST-200 | 6 | |
| Buffer bucket | 4 | ||
| Pressure sensor | PST-1.5 | 12 | |
| Flexible auger | φ90mm | 2 | |
| Pressure sensor | PST-200 | 9 | |
| Premix micro scale system | 3 | ||
| Granulation | To be granulated bin | Total 137m³ | 3 |
| Level 1 Conditioner + Quality Assurer Combination Equipment | Conditioning time>3 minutes | 3 | |
| Wind shut | GFDZY-16 | 6 | |
| Bucket elevator | TDTG50/28 | 3 | |
| Cooler | AHLN28×28 | 3 | |
| Chakron | 2Xφ1300mm | 3 | |
| Crusher | DFZL-1500 | 1 | |
| Pellet machine feeder | TWLL25 | 3 | |
| Fan | 4-72-8C | 6 | |
| Pulse dust collector | AHMB6L | 3 | |
| Pneumatic tee | AHBQ250 * 35 ° | 10 | |
| air hammer | AH40 | 3 | |
| Feeder | 3 | ||
| Unloading level device | 3 | ||
| Animal feed pelleting machine | SZLH508 | 3 | |
| Buffer bucket | 1m³ | 3 | |
| Grading screen | AHJH130 * 2C | 3 | |
| Cooling wind net | Φ600mm | 3 | |
| Bale | Wind shut | GFDZY-10 | 3 |
| Double bucket powder electronic packing scale | 1 | ||
| Double bucket pellet electronic packing scale | 3 | ||
| Fan | 4-72-3.6A | 3 | |
| Finished product warehouse | Total 160m³ | 6 | |
| Pulse dust collector | AHMY18 | 3 | |
| Feeder | 12 | ||
| Pneumatic tee | AHBQ250 * 70 ° | 3 | |
| Unloading level device | 12 | ||
| air hammer | AH40 | 2 | |
| Single wing butterfly valve | DN400 | 1 | |
| Mixer | AHHJ4 | 1 | |
| Two-way distribution valve | TFPQv40*40 | 6 | |
| Vibrating screen | SFJH150 | 3 | |
| Buffer bucket | 1m³ | 6 | |
| Two-way distribution valve | TFPQv40*40 | 1 | |
| Wind net | φ300mm | 2 | |
| Cleaner | QFQ600 | 1 | |
| other | Air compressor | 2 | |
| Filter tank | 1.5m³ | 1 | |
| gas tank | 1.5m³ | 2 | |
| Freeze dryer |
Table 2 Annual consumption of raw and auxiliary materials
| product | Name of raw and auxiliary materials | Annual consumption (t/a) | source | Storage method | Maximum storage capacity |
| Livestock | Whey powder (low protein) | 100 | Bagged (50kg/bag), raw material warehouse storage | 3.5 | |
| glucose | 100 | Bagged (50kg/bag), raw material warehouse storage | 4 | ||
| Corn secondary | 47000 | Bagged (50kg/bag), raw material warehouse storage | 400 | ||
| Wheat secondary | 8000 | Bagged (50kg/bag), raw material warehouse storage | 0 | ||
| barley | 4000 | Bagged (50kg/bag), raw material warehouse storage | 100 | ||
| pea | 6000 | Bagged (50kg/bag), raw material warehouse storage | 200 | ||
| Coarse bran | 10000 | Bagged (50kg/bag), raw material warehouse storage | 15 | ||
| Rice bran | 2000 | Bagged (50kg/bag), raw material warehouse storage | 0 | ||
| Soy lecithin oil powder | 200 | Bagged (50kg/bag), raw material warehouse storage | 6 | ||
| Soybean oil level 1 | 200 | Bagged (50kg/bag), raw material warehouse storage | 3 | ||
| 46% soybean meal | 20000 | Bagged (50kg/bag), raw material warehouse storage | 100 | ||
| Fermented soybean meal | 200 | Bagged (50kg/bag), raw material warehouse storage | 11 | ||
| Fine stone powder | 200 | Bagged (50kg/bag), raw material warehouse storage | 20 | ||
| Dicalcium Phosphate | 20 | Bagged (50kg/bag), raw material warehouse storage | 10 | ||
| 98.5% lysine | 200 | Bagged (50kg/bag), raw material warehouse storage | 4.5 | ||
| Choline Chloride | 200 | Bagged (50kg/bag), raw material warehouse storage | 1.4 | ||
| Common phytase | 200 | Bagged (50kg/bag), raw material warehouse storage | 0 | ||
| L-threonine | 200 | Bagged (50kg/bag), raw material warehouse storage | 1.5 | ||
| Propionic acid type solid antifungal agent | 40 | Bagged (50kg/bag), raw material warehouse storage | 0.2 | ||
| Sodium chloride (96.5%) | 40 | Bagged (50kg/bag), raw material warehouse storage | 8 | ||
| Piglet composite premix SPV211A (powder/40kg) | 800 | Bagged (50kg/bag), raw material warehouse storage | 1 | ||
| Pig compound premix SPV216 (powder/40kg) | 800 | Bagged (50kg/bag), raw material warehouse storage | 1 | ||
| Breeding pig trace element premix SPM216 (powder/50kg) | 700 | Bagged (50kg/bag), raw material warehouse storage | 1 | ||
| Big pig trace element premix SPM214 (powder/50kg) | 700 | Bagged (50kg/bag), raw material warehouse storage | 5 | ||
| Complex antioxidant | 40 | Bagged (50kg/bag), raw material warehouse storage | 0.4 | ||
| Domestic ddgs | 200 | Bagged (50kg/bag), raw material warehouse storage | 30 | ||
| Expanded corn | 500 | Bagged (50kg/bag), raw material warehouse storage | 6 | ||
| Calcium sulfate | 30 | Bagged (50kg/bag), raw material warehouse storage | 0 | ||
| 40% sodium butyrate | 30 | Bagged (50kg/bag), raw material warehouse storage | 1 | ||
| Imported chicken powder | 300 | Bagged (50kg/bag), raw material warehouse storage | 0 | ||
| Poultry feed | Corn secondary | 90000 | Bagged (50kg/bag), raw material warehouse storage | 2000 | |
| barley | 10000 | Bagged (50kg/bag), raw material warehouse storage | 300 | ||
| pea | 10000 | Bagged (50kg/bag), raw material warehouse storage | 300 | ||
| Coarse bran | 6000 | Bagged (50kg/bag), raw material warehouse storage | 30 | ||
| Rice bran | 10000 | Bagged (50kg/bag), raw material warehouse storage | 20 | ||
| Soybean oil level 1 | 6000 | Bagged (50kg/bag), raw material warehouse storage | 20 | ||
| 46% soybean meal | 30000 | Bagged (50kg/bag), raw material warehouse storage | 900 | ||
| corn protein flour | 4000 | Bagged (50kg/bag), raw material warehouse storage | 30 | ||
| Sprayed corn husk | 4000 | Bagged (50kg/bag), raw material warehouse storage | 200 | ||
| Fine stone powder | 8000 | Bagged (50kg/bag), raw material warehouse storage | 100 | ||
| Coarse stone powder | 4000 | Bagged (50kg/bag), raw material warehouse storage | 60 | ||
| Dicalcium Phosphate | 2000 | Bagged (50kg/bag), raw material warehouse storage | 30 | ||
| 98.5% lysine | 400 | Bagged (50kg/bag), raw material warehouse storage | 20 | ||
| Choline Chloride | 400 | Bagged (50kg/bag), raw material warehouse storage | 8 | ||
| Common phytase | 40 | Bagged (50kg/bag), raw material warehouse storage | 2 | ||
| Compound enzyme for poultry | 40 | Bagged (50kg/bag), raw material warehouse storage | 3 | ||
| Thermostable Phytase | 40 | Bagged (50kg/bag), raw material warehouse storage | 2 | ||
| Natural lutein (derived from marigold) | 20 | Bagged (50kg/bag), raw material warehouse storage | 2 | ||
| L-threonine | 400 | Bagged (50kg/bag), raw material warehouse storage | 6 | ||
| Sodium chloride (96.5%) | 400 | Bagged (50kg/bag), raw material warehouse storage | 10 | ||
| Trace element premix for meat and poultry BM02 (powder/50kg) | 1000 | Bagged (50kg/bag), raw material warehouse storage | 10 | ||
| Vitamin premix for meat and poultry BV02 (powder/40kg) | 1000 | Bagged (50kg/bag), raw material warehouse storage | 2 | ||
| Flour secondary | 4000 | Bagged (50kg/bag), raw material warehouse storage | 30 | ||
| β-carotene-4,4-dione (cantharidin yellow) | 20 | Bagged (50kg/bag), raw material warehouse storage | 0.1 | ||
| Domestic ddgs | 16000 | Bagged (50kg/bag), raw material warehouse storage | 300 | ||
| Attapulgite powder | 20 | Bagged (50kg/bag), raw material warehouse storage | 3.5 | ||
| 40% sodium butyrate | 20 | Bagged (50kg/bag), raw material warehouse storage | 5 | ||
| total | 514910 | / | / | ||
Table 3 List of product solutions
| product name | Specification (mm) | Output (t/a) | Packing standard (kg/bag) |
| Poultry feed | Powder | 12000 | 40 |
| Powder | 33000 | ||
| Powder | 7000 | ||
| Powder | 25000 | ||
| Medium damage | 5600 | ||
| Medium damage | 4500 | ||
| 2.0 | 13000 | ||
| 3.0 | 11200 | ||
| 2.0 | 2900 | ||
| 3.0 | 12000 | ||
| 3.0 | 6000 | ||
| 3.0 | 1600 | ||
| 2.0 | 3000 | ||
| 4.0 | 9000 | ||
| 4.0 | 1000 | ||
| 4.0 | 28000 | ||
| 4.0 | 3000 | ||
| 4.0 | 4000 | ||
| 4.0 | 1200 | ||
| 4.0 | 17000 | ||
| Total poultry feed | 200000 | / | |
| Pig feed | Medium damage | 1800 | 20 |
| Pig feed | 3.5 | 6500 | 40 |
| 4 | 12000 | ||
| 4 | 75200 | ||
| 4 | 2500 | ||
| 4 | 2000 | ||
| Total pig feed | 100000 | / | |
| Total livestock and poultry feed | 300000 | / | |
If you are also considering building a 1-100 t/h feed pellet production line project, please contact us. If your team is going to build a large capactity feed pellet production line, the advantage of choosing us is that RICHi will help you:
1. Determine the scale of animal feed mill.
2. Determine the feed process and recommend animal feed machine.
3. Control mode selection.
4. Animal feed manufacturing plant structure selection.
5. Planning the general drawing of animal feed mill plant site.
6. We devote ourselves to undertaking all feed production line 1-100T/H.
The above is the article for you: 200,000 Tons/year Livestock Poultry Feed Line & 100,000 Tons/year Pig Feed Pellet Production Line Project.
If you are interested in our products or project solutions, please contact us. We will give you the best product quality and the best price. Email: enquiry@pellet-richi.com
