6 Pellet Machines Are Used in the Production Line of 20,000 Tons of Chaff Pellets Per Year
6 Pellet Machines Are Used in the Production Line of 20,000 Tons of Chaff Pellets Per Year

The actual total investment of this project is 500,000 yuan, with an annual output of 20,000 tons of environmentally friendly biomass pellets and 10,000 tons of chaff. The basic situation of the project is shown in Table 1.

Table 1 List of basic information of this project

project name Annual production of 20,000 tons of environmentally friendly biomass pellets and 10,000 tons of bran production project
Location Shuangfengshu Village, Lanxi Town, Heshan District, Yiyang City
Project nature New Industry category and code Non-metallic waste and scrap C4220 plus
-tasking
Area 3200m2 Production scale Annual production of 20,000 tons of environmentally friendly biomass pellets
and 10,000 tons of chaff

Investment situation
It is estimated that the total investment of the project is 500,000 yuan, and the environmental protection investment is about 180,000 yuan, accounting for 36% of the total investment
The actual total investment is 500,000 yuan, and the environmental protection investment is about 180,000 yuan, accounting for 36% of the total investment
Start time November 2016 Completion time January 2017
Labor quota 6 people Work system 8 hours a day, 300 working days per year

Environmental assessment and approval status
April 2019, Hunan food bio-energy Co., Ltd. entrusted Hunan known as Environmental Services Ltd. prepared the "Lake
Nanxiang food Bioenergy Ltd. annual output of 20,000 tons of green biomass particles and 10,000 tons of rice bran environmental impact of production projects
Report Form”, which was approved by the Heshan Branch of the Yiyang City Ecological Environment Bureau on April 30, 2019. The approval document number is Yihuan Heshen (Form) [2019] No. 13.

Table 2 List of main construction contents of the project

Serial number Environmental impact assessment construction Actual construction situation




structural work




Production workshop

Biomass pellet production workshop
The first floor, with a steel frame structure, has a building area of ​​about 1200m2
(30m×40m), one side is 15m high, and it is located on the east side of the factory area. It has 6 production lines with a production scale
of 20,000 tons per year.




Consistent with EIA

System chaff production workshop
Layer, steel frame structures, building area of 1200m2
(30m × 40m), a height of 15m, located next to the raw material particle production plants, production lines 4 arranged raw
production scale of 10,000 tons / year.




Storage and Transportation Engineering
Raw material library Floor area of approximately 500m2 (20m × 25m), a height of 15m, stockpile
field for stacking the collected material.




Consistent with EIA
Raw material bucket Composed of 10 hoppers and a prismatic steel frame structure, each hopper
can branch out 2 outlets, the maximum storage is about 200t.
Finished bucket It consists of 10 hoppers and a prismatic steel frame structure, with a maximum reserve of
about 200t.
Finished product library The building area is about 200m2, and it is used to stack the finished products (including
chaff and biomass pellets) packed in bags and sealed .


Auxiliary engineering
office One-story building, brick-concrete structure, building area is about 100m2, located
on the north side of the entrance .


Consistent with EIA
Floor Located on the north side of the plant, the area is about 100m2. Ground hardening, for car
vehicles parked.


Public works
Water supply Part of the water used in the plant is provided by the municipal pipe network. Consistent with EIA
powered by The power for the plant is supplied uniformly by the local power supply network. Consistent with EIA
drain Rain and sewage diversion system for plant drainage Consistent with EIA










Environmental Engineering

Wastewater treatment
The rainwater and sewage diversion system is implemented in the plant area, and rainwater is discharged into the surrounding ditches through the rainwater pipe network. There is no production wastewater generated in this project. The domestic sewage is treated in the septic tank and
used as agricultural fertilizer and not discharged.

Consistent with EIA





Waste gas treatment
The plant area uses a closed airtight duct to transport materials; the dust in the material is treated by a bag filter and a pulse dust collector + 15m high exhaust cylinder, and then discharged up to the standard. The escaping dust settles by gravity; part of the dust produced by granulation follows Water vapor is discharged from the external environment, part of which is settled to the ground by gravity, part of the dust generated by pulverization is discharged from the external environment with water vapor, and part of the dust is settled to the ground by gravity for cleaning; storage yard dust, air duct dust, bag dust collector dust, granulating dust ,, pulse dust, grinding dust and dust are settled to the conveyor belt surface, the cleaning by gravity
processing.


The material dust is discharged through the bag filter and the pulse dust collector after being cleaned regularly after being unorganized


Solid waste treatment
The solid waste of this project is mainly employee domestic garbage, waste lubricating oil barrels, and collected dust; the waste lubricating oil barrels are temporarily stored in the hazardous waste temporary storage room and handed over to the relevant hazardous waste disposal unit for outbound disposal. Domestic garbage and collected dust dust by garbage
barrel after collection by the sanitation department of the removal process.


Consistent with EIA
Noise prevention Choose low-noise equipment and take measures such as shock absorption, sound insulation and reasonable layout. Consistent with EIA

1. Chaff Pellet Production Line Project Product Plan

The project will produce 20,000 tons of shaped biomass pellets and 10,000 tons of chaff annually. The specific product plan is shown in Table 3.

Table 3 List of project product plans

name unit Annual output Remarks
Molded biomass pellet products
Ten thousand tons

2
The raw material is mainly chaff. The formed biomass particles have a diameter of about
8mm, a length of about 8cm, ash content≦8.0%, density≧1.1t/m3, and low calorific value 3200kg/kcal. The moisture content of the finished product is less than 5%.
Thong Ten thousand tons 1 /

2. Main Raw and Auxiliary Materials and Energy

Compared with the EIA report and its approval stage, the raw and auxiliary materials and energy usage are the same. For details, see Table 4:

Table 4 List of project raw and auxiliary materials consumption

Serial number name consumption Remarks
1 Chaff About 35,000 tons/a (23,000
tons/a of biomass pellets and 12,000 tons/a of chaff)
Outsourcing from the market, surrounding rice factories, moisture content of raw materials
≦12%
2 Electricity About 125,000 kW·h/a Local grid
3 water 110t/a Municipal Pipeline

3. The Main Production Equipment of Chaff Pellet Production Line Project

Compared with the EIA report and its approval stage, the use of main production equipment is the same. For details, see Table 5:

Table 5 List of Major Equipment List

Serial number Equipment name Quantity unit Remarks
1 Rice Husk Pellet Mill 6 station

Biomass particles
2 Bag filter 1 set
3 Fan 1 station
4 Belt conveyors 2 station


Share
5 Forklift 2 station
6 Air duct About 30m long m
7 Hoist 3 station
8 transformer 2 station
9 grinder 4 station

Thong
10 pulse 4 station
11 Fan 4 station

4. Production Process

Introduction to the production process of biomass pellets:

The process of this project has strict requirements on the moisture content of raw materials. According to the information provided by the construction unit, the moisture content of the raw materials purchased in this project is less than 12%, and the moisture content of the finished product is not higher than 5%.

①Raw materials

The raw materials are stored in the raw material warehouse, and the raw materials are transported through the airtight duct, and loading and unloading dust will be generated in the raw material warehouse.

② Lifting by hoist

The materials transported by the air duct are lifted to the next process through the hoist, and dust will be generated in this process.

③Dust removal by dust collector

The material lifted by the hoist is dusted by the dust collector and then transported to the raw material hopper. Dust will be generated in this process.

④Granulation machine granulation

The material in the raw material hopper is transported to the feed inlet of the rice husk pellet mill due to the action of the center of gravity. Under the conditions of high temperature and high pressure, the water vapor is discharged to the atmosphere through the pipeline in the form of water vapor, and the water vapor is condensed into liquid water through the pipeline and discharged to the septic In the tank, the raw materials are compressed into shaped biomass particles, which are transported to the next process by a belt conveyor. Electric heating is used in the granulation process. This process generates dust.

⑤Conveyor belt

After being processed by the pelletizer, the formed biomass particles fall from the discharge port to the sealed belt conveyor, and are transported to the elevator by the sealed belt conveyor. This process generates dust.

⑥ Lifting and cooling of hoist

The elevator lifts and conveys the formed biomass particles to the raw material hopper, and adopts air cooling during the conveying process. The front cooling process is closed and uses electric energy. This process generates dust.

⑦The finished product is bagged and stored

After cooling, the formed biomass particles are temporarily stored in the finished product hopper, and some finished products are bagged and sealed in the finished product warehouse. This process generates dust.

Production Process

①Raw materials

The raw materials are stored in the raw material warehouse, and the raw materials are transported through the airtight duct, and the storage yard dust will be generated in the raw material warehouse.

② Lifting by hoist

The materials transported by the air duct are lifted to the next process through the hoist, and dust will be generated in this process.

③Pulse dust collector

The material lifted by the hoist is dedusted by the pulse dust collector and then transported to the raw material hopper. This process will generate dust.

④Crushing by crusher

The material in the raw material hopper is transported to the feed inlet of the crusher due to the center of gravity. Under the condition of high temperature and high pressure,

The water vapor is discharged to the atmosphere through pipelines in the form of water vapor. The water vapor is condensed into liquid water through the pipeline and discharged to the septic tank. The raw materials are compressed into molded bran and transported to the next process by a belt conveyor. The crushing process uses electric heating. This process generates dust.

⑤Conveyor belt

After being processed by the rice husk pellet mill, the chaff falls from the discharge port to the belt conveyor, and is conveyed by the belt conveyor to the hoist. This process generates dust.

⑥ Lifting machine

The hoist will lift the chaff to the raw material hopper to use electric energy. This process generates dust.

⑦The finished product is bagged and stored

The formed chaff is temporarily stored in the finished product bucket, and some finished products are stored in the finished product warehouse after bagging and sealing. This process generates dust.

⑧SaleThe finished product is sold out.

The entire production process of the project is completed on a closed assembly line, and the belt conveyor process is open. This project is equipped with 2 belt conveyors, one is used to evenly distribute the formed biomass particles in the finished product bucket. One is used to evenly distribute the chaff in the finished product bucket.

chaff pellet
chaff pellet

We provide chaff pellet production line of 1-100 tons/hour, which is what we often call rice husk pellet production line. We produce various biomass pellet production line projects. If you are interested in our products, please contact us!
