Silage Bale Chopper in Spain

Project Background: The Need for a Dedicated Single Unit

Our client is a medium-to-large scale animal feed preparation contractor serving dairy and sheep farmers across the Ebro Valley. For years, this contractor relied on outdated tractor-mounted tub grinders to break down round bales before mixing Total Mixed Rations TMR. But as they scaled up to supply more farms, the bottleneck became obvious.

Their existing equipment was struggling with the hard-packed, high-density silage bales common in Spain. The old machines would jam, or they would spit out long, uncut strings of straw—often exceeding 300mm—which the cows would sort out of the feed, leading to waste and lower milk yields. The client realized he didn't just need a grinder; he needed a heavy-duty industrial bale chopper capable of consistent, fine particle size 20-30mm to improve feed digestibility.

He visited our factory in China to see the manufacturing process firsthand. He specifically chose to purchase two units of the YPPK-2600 model. Why two? He didn't need a full automated production line this time, as he has flexible storage pits. Instead, he wanted two independent mobile units to create a “parallel processing” station. One unit processes alfalfa while another processes straw, allowing him to blend directly from the output conveyor belts into his mixer wagon, doubling his throughput during the busy morning feed prep window.

Machine Selection: Why the YPPK-2600 for Spanish Alfalfa?

Our client needed a robust solution for his harsh working environment. He selected the YPPK-2600 because it perfectly matched the 1.8m diameter bales common in his region.

The client feeds a mix of 30% dry alfalfa for protein and 70% cereal straw for fiber. The YPPK-2600 processes these bales down to a consistent 20-30mm length without dusting thanks to the optional dust control system he added. This specific size is critical for Spanish dairy rations; too fine and it causes acidosis, too long and it’s wasted. The 20-30mm goldilocks zone ensures the rumen functions properly.

Key Technical Advantages on the Spanish Farm

Why did this contractor trust our machinery over expensive European brands like Kverneland or Elho? It came down to industrial durability and specific design features that his local Juscafresa dealer couldn't provide at the same price point.

1. The Damping Plate Anti-Blockage System

The farmer in Lleida specifically mentioned the damping plate inside the crushing chamber. He processes dry bales that often contain small stones from the Spanish fields. The damping plate increases the material grip force, preventing the rotor from just bouncing off the bale surface. It grabs the material and forces it into the hammer zone.

2. Heavy-Duty Transmission & Carbide Hammer Tips

Spanish contractors run their machines hard—often 10-12 hours a day during the winter prep season. He was impressed by our thickened transmission chain and the Tungsten Carbide overlay welding on the hammers. Standard hammers in Spain wear out quickly against the silica in alfalfa. Our 65Mn steel hammers with carbide tips keep the crushing efficiency high without weekly maintenance.

3. Gear External Chain Rotary Cutting

Unlike vertical mixers that just shred, our gear external chain rotary cutting mechanism provides a no dead corner cut. This ensures that even the tough knot in the center of the bale is broken down. The client noted that his TMR mixer now runs smoother because there are no long strands wrapping around the auger.

Logistics: Shipping from Qingdao to Barcelona

The client purchased the two YPPK-2600 units under FOB Qingdao terms. We prepared the machines at our manufacturing hub, applying a special anti-corrosion wax coating to protect against the sea salt air during the long voyage.

• Loading Port: Qingdao, China
• Shipping Route: Transit through the South China Sea, across the Indian Ocean, through the Suez Canal, into the Mediterranean.
• Destination Port: Port of Barcelona, Spain.
• Logistics Note: From Barcelona, the client arranged flatbed trucks to transport the 2.2-ton units the 150km inland to Lleida. Because the dimensions 3800*2600*2650mm fit standard high-cube containers neatly, shipping costs were kept surprisingly low, making the total investment much more attractive than buying a bulky European machine.

Versatility of the Equipment Beyond Breaking Bales

Although the client uses this for feed preparation, we educated him on the broad utility of this hammer mill system for agricultural waste management, which is a growing concern in Spain due to new EU burning bans.

Because this is a coarse crusher machine achieving 20-30mm rather than powder, it is perfect for:

1. Composting: Breaking down corn stalks and pruning remains to accelerate composting for almond orchards.
2. Biogas: Pre-treating agricultural waste before it enters an anaerobic digester AD plant. Spanish biogas operators are now looking at this model to standardize particle size for bacteria.
3. Bedding: Dry chopped straw can be blown directly into free stalls for livestock bedding.

The client appreciated that if his feed business contracts in the future, the silage bale chopper holds resale value as a versatile biomass processor.

Customer Feedback & Site Report 6 Months Post-Installation

We followed up with the site manager via video call last month. Here is the raw feedback from the head operator, Juan translated from Spanish:

The difference is night and day compared to our old tractor mill. Before, we had to stop every 20 minutes to clean out wrapped straw. With the RICHI YPPK-2600, we feed two bales side-by-side, and it just eats them. We run it for four hours straight non-stop.

The output size is so uniform that the professional nutritionist actually increased the percentage of home-mixed roughage because he knows there is no sorting waste. The casing is heavy—you feel the quality when you look at the welding seams. It sits outside in the Lleida weather, and we have no rust issues.

The only change we made was adding an extra light above the feed hopper for night shifts. For the price of one European machine, we got two RICHI units, which means if one is down for a hammer change, we keep running. That is peace of mind.

Comprehensive Services Provided by RICHI Machinery

To ensure the Spanish contractor felt secure moving away from local European suppliers, RICHI Machinery offered a customized service package:

• Custom Voltage: We adapted the motor to 400V/50Hz Spanish grid standard with CE-verified electrical components.
• Spare Parts Kit: We included a full starter kit of spare hammers, pins, and a heavy-duty chain link specific to the YPPK-2600. We know that shipping from China takes 35 days, so we overstocked him for 6 months of heavy wear.
• Remote Commissioning: Because sending a technician to Spain is expensive, we pre-assembled and test-ran the machines in Qingdao. We painted alignment marks on all bearings and bolts. A RICHI engineer walked him through the final assembly via WhatsApp video in just 2 hours.

A Smart Investment for the Mediterranean Livestock Sector

The Silage Bale Chopper in Spain is not just a machine; it is a solution to the logistical problem of high-density Mediterranean bales. For this contractor in Lleida, moving from a tractor-powered tub grinder to two dedicated YPPK-2600 units transformed his yard. He reduced his processing time by 40%, improved feed efficiency for his clients, and lowered his maintenance headaches.

If you are in Spain, France, or Italy facing the same issues with tough, dry bales for your TMR mixer machine or recycling operation, the YPPK series offers an industrial-grade, cost-effective alternative to the local competition. Contact RICHI Machinery for a site assessment or to request a sample hammer tip for hardness testing.
