8T/H Manure Granulator in Poland

Customer demand analysis

At the beginning of the manure granulator in Poland project, the customer explained his needs to us in detail.

• First of all, it is necessary to convert manure into organic fertilizer granules that meet EU standards to achieve resource value-added, and it is expected that annual income can increase by 1.5 million euros.
• Secondly, strict environmental protection requirements must be met, including a reduction of more than 60% in ammonia emissions and heavy metal content in compliance with EU Fertilizer Product Regulation (EC) 2019/1009.
• The most important thing is to establish a circular agricultural model, use organic fertilizers on the company's own 3,000 hectares of arable land, and reduce the use of chemical fertilizers by 30%.

The customer put forward four core requirements for selection of manure granulator in Poland:

• It must adapt to the extreme climate in Poland and can still operate stably at -20℃;
• The processing capacity must match the farm manure production and achieve continuous production of 8 tons/hour (dry basis);
• It can simultaneously process mixed raw materials of chicken manure (high nitrogen) and cow manure (high fiber);
• The energy consumption of the whole line is controlled within a reasonable range, in compliance with the EU Ecodesign Directive.

Technical advantages of RICHI manure granulator in Poland

According to customer needs, the final equipment for this organic fertilizer production project is a FZLH420 manure pelleting machine. The pelleting system adopts innovative "low temperature granulation" technology to keep the processing temperature below 60℃ and retain nutrients to the maximum extent. The particle diameter is designed to be 4mm and 6mm.

The former is used for mechanized fertilization, and the latter is suitable for the home gardening market. The final product is cooled to within +5℃ of the ambient temperature through a countercurrent cooling system to avoid condensation and quality deterioration.

RICHI ring die manure granulator in Poland is specially designed for the resource utilization of organic waste such as livestock and poultry manure, sludge, straw, etc.

It combines efficient granulation technology, wear-resistant technology and intelligent control system to meet customers' high requirements for organic fertilizer particle forming rate, production efficiency and equipment stability. The following are the six core advantages of this equipment:

• Special alloy material: chromium-molybdenum alloy steel (surface hardness HRC58-62), carburized quenching + deep cryogenic treatment, wear resistance is 3 times higher than that of ordinary molds, and the service life is more than 3,000 hours.
• Variable aperture structure: The mold hole adopts a stepped design (large inlet → small outlet) to ensure that high-fiber materials (such as cow dung and straw) pass smoothly and the particles are dense.
• Quick change system: hydraulic assisted disassembly and assembly, the time for replacing the ring die is ≤30 minutes (traditional equipment takes 2 hours).
• Heavy-duty bearing system: equipped with SKF high-load bearings, lubrication adopts centralized oil supply device to ensure 24-hour continuous operation.
• Hydraulic pressure compensation: the gap between the pressure rollers can be dynamically adjusted (0.1~0.5mm), automatically compensate for wear, and maintain stable forming pressure.
• Low vibration design: the spindle is dynamically balanced (vibration value ≤2.5mm/s) to reduce equipment fatigue loss.
• Frequency conversion speed regulation system: automatically adjust the spindle speed (18~35rpm) according to the material characteristics to optimize the production capacity and energy consumption ratio.
• Optimized power configuration: power consumption per ton of material ≤25kWh (15%~20% lower than the industry average). Forming rate ≥95% (traditional equipment is about 85%~90%), crushing strength ≥12N (meeting the requirements of mechanized fertilization), smooth particle surface, adjustable diameter (3~8mm).
• Closed structure: With pulse dust removal, the dust concentration in the working area is less than 10mg/m³ (in compliance with OSHA standards).
• Self-cleaning system: The roller is designed with a scraper to prevent material adhesion and reduce the frequency of shutdown for cleaning.
• Modular maintenance: Key components such as gearboxes and bearings can be quickly disassembled to reduce maintenance time costs.
• Raw material test optimization: Free material trial production is provided to determine the optimal ring die compression ratio, moisture content and other parameters.

RICHI ring die cow dung chicken manure pellet machine takes high reliability, low operating costs and intelligent operation as its core competitiveness, helping customers achieve efficient value-added utilization of organic waste. Targeted solutions can be provided according to specific raw material characteristics (fiber content, viscosity, etc.).

Raw material characteristics

The raw material system used in this manure organic fertilizer production line project makes full use of its own resources. Chicken manure comes from caged laying hen farms, with a moisture content of about 65% and a total nitrogen content of 3.5-4.0%, which is the main source of nitrogen; cow manure comes from dairy cow sheds, with a moisture content of 80%, a high organic matter content (about 18%), but longer fibers.

The two types of manure are mixed in a ratio of 3:1, 10% straw powder is added to adjust the carbon-nitrogen ratio, 5% humic acid is added to improve the cation exchange capacity, and 3% bentonite is used as a natural binder.

Product standards and market positioning

The manure granulator in Poland project produces two types of organic fertilizer products.

1. Basic-level granular fertilizer mainly meets the basic requirements of EU fertilizer regulations, with total nutrients (N+P2O5+K2O) ≥5%, organic matter ≥60%, and heavy metal content below the limit of 80%. This type of product is mainly used for self-owned farms and surrounding contract farmers, replacing 30% of chemical fertilizers.
2. High-end value-added products target the Western European organic agriculture market. By adding specific microbial agents (nitrogen-fixing bacteria, phosphate-dissolving bacteria, etc.), it has obtained the German BCS organic certification and the French ECOCERT certification.
3. The product packaging is divided into 25kg bags (retail market) and 1 ton big bag (large farms), and the price is 2-3 times that of the basic level. A specially developed improved formula for sandy soils, with additional humic acid (8%) and diatomaceous earth (5%), increased potato yields by 15% in local trials.

Under the strict EU environmental regulations, innovative manure treatment technology can not only solve environmental problems, but also create significant economic benefits, providing a successful model for sustainable agricultural development in Central and Eastern European countries.

If you are interested in this manure granulator in Poland project, want to learn more about the equipment, watch the operation video, feel free to contact RICHI MACHINERY!
